IM 4000 A3 black and white multifunction printer

  • Copy, print, scan, optional fax
  • Prints up to 40 ppm
  • Continuous updates via RICOH Always Current Technology
  • RICOH Smart Integration workflows

Professional print solutions on demand

Effortlessly boost office productivity thanks to innovative high-speed scanning, Always Current Technology and an extensive range of finishing options for professional-looking printed documents every time.

Digital document storage made easy

At Ricoh, we’ve made it so easy to convert paper-based information to digital format for fast and convenient digital storage. Simply scan documents directly to your preferred cloud storage apps or private network. We’ve even built in as standard multi-layered security features designed to keep your documents safe and secure.

  1. Fast and convenient digital storage
    Scan documents directly to your preferred online storage app or network as you go.
  2. Integrate seamlessly with any new technology you bring onboard
    With Ricoh’s Always Current Technology, your employees can download upgrades to any device they use so their tools are always current.
  3. A professional print finish every time
    Access a suite of tools to give your documents that professional print finish and wrap without having to outsource.
  4. Technology and security simply built in
    Our multi-layered security features make digital document management risk proof.

Download PDF brochure



Specifications

功用
Copy, print, scan, optional fax
存儲
320 GB
記憶體 - 標準
4 GB—2 GB mainframe + 2 GB Smart Operation Panel
操作板面
10.1-inch Smart Operation Panel (G2.5)
實體尺寸(長闊高)—大型機
587 x 673 x 788 mm
重量—大型機
62.5 kg or less
標準輸入量(張)
1,200
最大輸入量(張)
4,700
標準輸出量(張)
500
最大輸出量(張)
3,625
紙張輸入配置 - 標準
2 x 550-sheet paper trays, 100-sheet bypass tray, duplex unit
紙張輸出配置 - 標準
500-sheet face-down internal output tray
支援媒體

Tray 1 and 2
Plain paper, recycled paper, colour paper, special paper, letterhead, preprinted paper, bond paper, card stock, plain paper backside, envelope, thin paper, plain paper 1–2, middle thick, thick paper 1–4

Optional trays
Plain paper, recycled paper, colour paper, special paper, letterhead, preprinted paper, bond paper, card stock, plain paper backside, thin paper, plain paper 1–2, middle thick, thick paper 1–4

Bypass tray
Plain paper, recycled paper, colour paper, special paper, letterhead, preprinted paper, bond paper, card stock, OHP, label, plain paper backside, envelope, thin paper, plain paper 1–2,  middle thick, thick paper 1–4

Note: Plain paper is not displayed as a paper type.
最大紙張尺寸
SRA3
媒體量
52–300
介面 - 標準

Mainframe
10Base-T/100Base-Tx (Ethernet)
1000Base-T (Gigabit Ethernet)
USB Host Type A—2 ports
USB Type B—1 port

Smart Operation Panel
IEEE 802.11 b/g/n (Wireless LAN)1
Bluetooth2
SD card slot—SDHC memory card
USB Host Type A—USB Flash memory
USB Host Type A—1 port for USB keyboard2
USB Host Type mini B—for NFC card reader2
NFC tag2

1—Limited printing for a peer-to-peer mobile device via RICOH Smart Device Connector
2—Cannot be used for printing

介面 - 可選

IEEE 1284
IEEE 802.11a/g/n (Wireless LAN)
Device Server Option Type M37 (additional Ethernet/Gigabit Ethernet port)

網路協議 - 標準
TCP/IP (IPv4, IPv6)
影印速度
40 cpm
首次影印時間
4.0 seconds
影印解像度

100, 200, 300, 400, 600 dpi

Note: Copy resolution when scanning.

縮放範圍
25%–400% in 1% steps
放大比例
115%, 122%, 141%, 200%, 400%
縮放比例
93%, 82%, 75%, 71%, 65%, 50%, 25%
雙面影印
Simplex to duplex, duplex to duplex—with ARDF/SPDF, book to duplex, front and back to duplex
書本影印
Booklet, magazine, layout and booklet
身份證影印
Supported
黑白列印速度
40 ppm
首次列印時間
3.6 seconds
列印解像度

300 x 300 dpi, 600 x 600 dpi, 1,200 x 1,200 dpi

Note: Print speed is decreased when Image Quality Priority Mode is chosen.





頁面描述語言

Standard
PCL 5e, PCL 6, PostScript 3 emulation, PDF Direct emulation

Optional
Genuine Adobe PostScript 3, PDF Direct from Adobe, XPS Direct Print, IPDS

印表機驅動程式

PCL 5, PCL 6, PostScript 3 emulation

雙面列印
Standard
行動列印
Yes
從USB/SD列印
Supported
掃瞄速度

80 ipm—via ARDF

Via SPDF
120 ipm—simplex, 200 x 200 dpi
110 ipm—simplex, 300 x 300 dpi
240 ipm—duplex, 200 x 200 dpi
180 ipm—duplex, 300 x 300 dpi

掃瞄模式

Scan to USB/SD, Scan to email, Scan to folder (SMB, FTP), Scan to URL, Scan to PDF/A, Scan to digitally signed PDF, Scan to searchable PDF (embedded)

色彩掃瞄
Standard
掃瞄解像度
100 dpi, 200 dpi (default), 300 dpi, 400 dpi, 600 dpi
掃瞄至檔案類型

Single- and multi-page TIFF
Single-page JPEG
Single- and multi-page PDF, PDF/A
Single- and multi-page high-compression PDF

掃瞄至電子郵件

Protocols
SMTP gateway, POP, IMAP 4

Authentication

SMTP authentication, POP before SMTP authentication

Scan resolution
100 x 100 dpi, 200 x 200 dpi, 300 x 300 dpi, 400 x 400 dpi,
600 x 600 dpi; default 200 x 200 dpi

Scan to email file types
Single-page
TIFF, JPEG, PDF, PDF/A, high-compression PDF, encrypted PDF, searchable PDF

Multi-page
TIFF, PDF, PDF/A, high-compression PDF, encrypted PDF, searchable PDF

Note: Optional OCR unit is required to support scanning to a searchable PDF.

掃瞄至資料夾

Protocols
SMB, FTP

Security
Client folder logon, transmission encryption of logon name and password

Resolution
100 x 100 dpi, 200 x 200 dpi, 300 x 300 dpi, 400 x 400 dpi,
600 x 600 dpi; default 200 x 200 dpi

Search for client folders
SMB—browsing directly to the designated folder
FTP—by folder name

Scan to folder file types
Single-page
TIFF, JPEG, PDF, PDF/A, high-compression PDF, encrypted PDF, searchable PDF

Multi-page
TIFF, PDF, PDF/A, high-compression PDF, encrypted PDF, searchable PDF

Note: Optional OCR unit is required to support scanning to a searchable PDF.

TWAIN掃瞄

Scan mode
Standard, Photo, OCR, Filing

Scan resolution
100 x 100 dpi–1,200 x 1,200 dpi

傳真類型
G3 fax, Internet fax (T.37), IP fax (T.38), LAN-Fax, Paperless fax, Direct SMTP fax
傳真機電路
PSTN, PBX
傳真兼容性
ITU-T (CCITT), G3—maximum 3 lines
傳真數據機速度
2,400 bps–33.6 Kbps—G3, standard with automatic shift down
傳真壓縮方法
MH, MR, MMR, JBIG
傳真解像度

Standard mode
200 x 100 dpi—8 x 3.85 lines/mm

Detail mode

200 x 200 dpi—8 x 7.7 lines/mm

Super fine mode
400 x 400 dpi—8 x 15.4 lines/mm
400 x 400 dpi—16 x 15.4 lines/mm

Note: Super fine mode is supported with the optional SAF memory.

G3傳真傳送速度
2 seconds approximately—JBIG, ITU-T No. 1 chart, TTI off, memory transmission
3 seconds approximately—MMR, ITU-T No. 1 chart, TTI off, memory transmission
傳真SAF記憶體容量
Standard
4 MB—approximately 320 pages

With optional SAF memory

60 MB—approximately 4,800 pages
傳真記憶體備份
1 hour
快速撥號
2,000 numbers
數據覆寫保安系統(DOSS)- 標準
Yes
數據覆寫保安系統(DOSS)- 可選
Type M19—available for customers who require their devices to comply with ISO 15408 Common Criteria certification
加密功能

HDD, PDF, Secure print encryption
Authentication password encryption
Encryption of data sent via Scan to email and Fax forwarding (S/MIME)

認證

802.1x wired authentication
IEEE 802.11i security (WEP, WPA)
IPv6
Quota setting/Account limit
User authentication—Windows and LDAP via Kerberos, basic, user code
User code authentication
Wi-Fi Protected Setup (WPS) support

Windows

Windows 8.1
Windows Server 2012
Windows Server 2012 R2
Windows 10
Windows Server 2016
Windows Server 2019



Macintosh
OS X Native v10.13 or later—PostScript 3 only
UNIX
Sun Solaris—10
HP-UX—11.x, 11iv2, 11iv3
Red Hat Linux—Enterprise, 4.x, 5.x, 6.x
SCO OpenServer—5.0.7, 6.0
IBM AIX— 6.1, 7.1, 7.2
SAP
Environment—R/3, S/4
Platform—SAP R/3 (Release versions 3.0 and higher), SAP R/3 Enterprise, mySAP ERP (2004 and higher), SAP HANA
Page Description Language (PDL)—PCL
Character set—Latin-1, Latin-2, Unicode
Barcode fonts—Code 128, Code 39, Code 93, Codabar, 2 of 5 interleaved/Industrial/Matrix, MSI, USPS Postnet, UPC/EAN
OCR fonts—OCR A, OCR B
Other supported features—Available for the printing of all SAP document types (SAPScript, Smartforms, ABAP)

標準
@Remote Embedded
Web Image Monitor
可選

@Remote
RICOH Smart Integration
Streamline NX v3
Global Scan NX
Card Authentication Package
Enhanced Locked Print NX
Device Manager NX Lite
Device Manager NX Accounting
Printer Driver Packager NX
@Remote Connector NX





手機應用程式
RICOH Smart Device Connector
電源
220–240 V, 50/60 Hz, 8 Amps—Asia Pacific
110 V, 60 Hz, 13.6 Amps—Taiwan
耗電量
1,780 W or less—maximum power
568 W—operating power
64.7 W—Ready Mode
0.57 W—Energy Saver Mode (Sleep Mode)
典型用電量
0.47 kWh
預熱時間

17.9 seconds

節能模式

60 seconds shift time—Energy Saver Mode (Sleep Mode)

恢復時間

From Energy Saver Mode (Sleep Mode)
7.4 seconds

其他環保功能
Eco-friendly indicator, On/off timer, duplex printing
